Bulletproof glass - Evo.Block
The bulletproof laminated glass of Sav 2000 provides protection against firearms attacks, being able to withstand repeated shootings from various types of weapons and bullets.
The glass resistance value varies according to the number of glass plates, their thickness and the number of plastic interlayer sheets used in the lamination process.
The Bulletproof glass must pass the ballistic test, according to European norm UNI EN 1063.
The norm distinguishes between two types of weapons: guns and rifles (BR classes) and buckshot guns (SG classes).Then, depending on the type of weapon, caliber, type of ammunition, shooting distance, etc. you rank the glass from BR1 to BR7 and SG1, SG2. A glass that meets the requirements for a particular class will also suit those of lower classes.
SAV 2000 laminates glass also with polycarbonate.
Advantages of bullet proof armored glass:
-
The use of this laminated glass is particularly suitable for preventing armed robbery attempts.
Ballistic test table
| Classe | Arma |
Calibro |
Tipo di munizioni |
Massa del proiettile (g) |
Distanza di tiro (m) | Velocità di impatto (m/s) | Numero di impatti | Distanza tra impatti (mm) |
|---|---|---|---|---|---|---|---|---|
| BR1 | Fucile | 0,22 Long Rifle | L/RN | 2,6±0,1 | 10,00±0,5 | 360±10 | 3 | 120±10 |
| BR2 | Pistola | 9 mm Luger | FJ1/RN/SC | 8,0±0,1 | 5,00±0,5 | 400±10 | 3 | 120±10 |
| BR3 | Pistola | 0,357 Magnum | FJ1/CB/SC | 10,2±0,1 | 5,00±0,5 | 430±10 | 3 | 120±10 |
| BR4 | Pistola | 0,44 Rem Magnum | FJ2/FN/SC | 15,6±0,1 | 5,00±0,5 | 440±10 | 3 | 120±10 |
| BR5 | Pistola | 5,56 x 45 * | FJ2/PB/SCP1 | 4,0±0,1 | 10,0±0,5 | 950±10 | 3 | 120±10 |
| BR6 | Fucile | 7,62 x 51 | FJ1/PB/SC | 9,5±0,1 | 10,0±0,5 | 830±10 | 3 | 120±10 |
| BR7 | Fucile | 7,62 x 51 ** | FJ2/PB/HC1 | 9,8±0,1 | 10,0±0,5 | 820±10 | 3 | 120±10 |
| SG1 |
Fucile da caccia | Cal 12/70 | piombo3 | 31,0±0,1 | 10,0±0,5 | 420±20 | 1 | - |
| SG2 | Fucile da caccia | Cal 12/70 | piombo3 | 31,0±0,1 | 10,0±0,5 | 420±20 | 3 | 120±10 |
Legend
* / Passo rigatura 178 mm ± 10mm | ** / Passo rigatura 254 mm ± 10mm | 1 / Proiettile con blindatura di acciaio dolce 2 / Proiettile con blindatura di lega di rame | 3 / Brenneke | L / Piombo | CB / Proiettile con ogiva di forma conica | FJ / Proiettile blindato | FN / Proiettile con ogiva troncoconica | HC1 / Nucleo in acciaio, massa 3,7 g ± 0,1g, durezza > 63 hrc | PB / Proiettile appuntito | RN / Proiettile con ogiva arrotondata | SC / Nucleo tenero (piombo) | SCP1 / Proiettile blindato (tipo SS 109) con nucleo tenero tondo e penetratore di acciaio
Table Evo.Block
| Name | Thickness |
Weight kg/sq |
Class |
Certificate |
|---|---|---|---|---|
| Evo.Block 12 | 12 | 25 | BR1/S | SI |
| Evo.Block 18 | 18 | 42 | BR1/NS | SI |
| Evo.Block 21 | 21 | 44 | BR2/S | SI |
| Evo.Block 22P | 22 | 39 | BR3/S | SI |
| Evo.Block 27 | 27 | 63 | BR3/NS | SI |
| Evo.Block 22PNS | 22 | 46 | BR4/S | SI |
| Evo.Block 32 | 32 | 73 | BR4/NS | SI |
| Evo.Block 24PNS | 24 | 51 | BR4/NS | SI |
| Evo.Block 35PNS | 35 | 76 | BR5/NS | SI |
| Evo.Block 44PNS | 44 | 96 | BR6/NS | SI |
| Evo.Block 78PNS | 78 | 180 | BR7/NS | SI |
